MEASURING EQUIPMENT
2.5D Projector
Toolmaker microscope is a measuring instrument, which moves stage XY to get the coordinates after the measurement point by means of the amount of movement measurement. The light emitted by light source is projected onto the project screen through the work piece to be measured, which can be dimensioned. Dimensional measurement usually can be included straightness, parallelism, verticality, symmetry, flatness, roundness, concentricity, coaxiality, and other geometric tolerance settings. In addition, it not only can be operated manually by multiple zoom lens system to avoid the lens magnification after the correction, but also can provide a variety of cross-line selections, standard circle and angle lines for fast alignment measurement.
3D Measurement
3D Coordinate Measuring Machine is the product of Mitutoyo. When the work piece has three axes to be measured, including point, line, plane, circle, oval, cylinder, cone, ball, arc, and keyway etc., once the work piece has been measured its simple of the geometric element decomposition that is to distinguish how many geometric elements of work piece composition, so that it can be quickly complete the measurement.
Full Image Measuring Instrument
The shape of target can be memorized and measured, and there is no need to care its position and direction on the stage. You can just simply press the measurement button. It is up to 3 seconds that can be measured up to 99 positions, and can be measured 100 units at the same time. If the tolerance is entered, it can also automatically determine the status of OK or NG. Furthermore, it can be dropped down work hours of measurement dramatically.
Torsion Tester
The machine is suitable for all kinds of testing such as the torque of screws, torsion springs, transmissions, and the other products’ torsion and life. Through the analysis of industrial computer which can accurately measure the torque and rotation angle of the measured object, and the speed of corresponding curve so that it can accurately control the rotation angle, rotation speed, and the numbers of target determination of screw torque test.
Depth Gauge / Tester
The depth of hole can be measured without breaking the work piece, and the thickness of probe can be changed according to the diameter of hole. Digital display is the way to let inspectors clearly know the depth of decision.
Roughness Tester
The sensor is put on the surface of work piece, and the inside of instrument drives its mechanism to drive the sensor along the measured surface to do the same speed. Then, the surface roughness of work piece has caused the displacement of stylus. The chip will be collected for data analysis and calculation, and the result of measurement can be read out.
Digital Micrometer Caliper
It is also known as micrometer or microcaliper which is a commonly used of instrument for length measurement. There are many types of micrometer, and the range of measurement and precision is different. The common range of measurement is 0-25mm, 25-50mm, 50-75mm, and the precision is 0.01mm and 0.001mm. The main purpose is to measure the outside of work piece such as the length, thickness, inner and outer diameter in accordance with the different uses divided into the inner diameter of micrometer, the outer diameter of micrometer, and the depth of micrometer.
